Flexible installation, perfectly adaptable to various commercial environments
● Key Feature Introduction
- Compact full-range speaker
- Suitable for restaurants, bars, terraces, and retail spaces
- low-frequency ventilation box
- 1-inch titanium diaphragm high-frequency driver with neodymium magnet structure
- Coherent covering waveguide
- Full-band overload protection (low and high frequencies)
- Elliptical weatherproof ABS enclosure
- Paintable black or white finish
- Magnetic shielding, suitable for video applications
- Strong arm mount for convenient and flexible directional adjustment
- T-type version, for 70V or 100V distributed systems
Specifications
| Specifications | |
| Frequency range (-10 dB) | 65 Hz – 20 Hz |
| Sensitivity (SPL, @1 W/1 m) | 89 dB |
| Maximum Sound Pressure Level (@ 1 m) | 115 dB |
| Power Drive (Continuous, Peak) | 100 W, 400 W |
| Transformer Taps | 70 V: 3.75 W 70 V / 100 V: 7.5, 15, 30 W |
| Coverage Angle | 120° × 80° |
| Low frequency drive | Dual 4″ |
| High-frequency drive | 1 inch |
| Rated impedance | 8 Ω |
| Input interface | Spring terminal |
| size | 310 mm × 175 mm × 216 mm |
| Net weight | 3.9 kg |
